Aluminum Bolt-On Radiation Horn for Speakers

Product image 1

Aluminum Bolt-On Radiation Horn for Speakers

The Pyle Bolt-On Type Radiation Horn - Material: Aluminum Cast - Nominal Coverage Angle (HxV)-6 dB: 90¦ x 40¦ - Cut Off Frequency: 1000 Hz - Throat Diameter: 25.40mm (1'') - Mounting Flange Diameter: 90mm - Mounting Hole Diameter: 7mm - Mounting Holes Number: 2N - Bolt Circle Diameter: 76 mm - Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D.
DETAILS
  • Material: Aluminum Cast
  • Nominal Coverage Angle (HxV)-6 dB: 90¬¶ x 40¬¶
  • Cut Off Frequency: 1000 Hz
  • Throat Diameter: 25.40mm (1'')
  • Mounting Flange Diameter: 90mm
  • Mounting Hole Diameter: 7mm
  • Mounting Holes Number: 2N
  • Bolt Circle Diameter: 76 mm
  • Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D
    MANUALS & DOWNLOADS

    PH2017 - Manuals

    PH2017 - Manuals

    • The Pyle Bolt-On Type Radiation Horn - Material: Aluminum Cast - Nominal Coverage Angle (HxV)-6 dB: 90¬¶ x 40¬¶ - Cut Off Frequency: 1000 Hz - Throat Diameter: 25.40mm (1'') - Mounting Flange Diameter: 90mm - Mounting Hole Diameter: 7mm - Mounting Holes Number: 2N - Bolt Circle Diameter: 76 mm - Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D.
    DETAILS
  • Material: Aluminum Cast
  • Nominal Coverage Angle (HxV)-6 dB: 90¬¶ x 40¬¶
  • Cut Off Frequency: 1000 Hz
  • Throat Diameter: 25.40mm (1'')
  • Mounting Flange Diameter: 90mm
  • Mounting Hole Diameter: 7mm
  • Mounting Holes Number: 2N
  • Bolt Circle Diameter: 76 mm
  • Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D
    MANUALS & DOWNLOADS

    PH2017 - Manuals

    PH2017 - Manuals

    • $17.59
    Aluminum Bolt-On Radiation Horn for Speakers—
    $17.59

    Description

    The Pyle Bolt-On Type Radiation Horn - Material: Aluminum Cast - Nominal Coverage Angle (HxV)-6 dB: 90¦ x 40¦ - Cut Off Frequency: 1000 Hz - Throat Diameter: 25.40mm (1'') - Mounting Flange Diameter: 90mm - Mounting Hole Diameter: 7mm - Mounting Holes Number: 2N - Bolt Circle Diameter: 76 mm - Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D.
    DETAILS
  • Material: Aluminum Cast
  • Nominal Coverage Angle (HxV)-6 dB: 90¬¶ x 40¬¶
  • Cut Off Frequency: 1000 Hz
  • Throat Diameter: 25.40mm (1'')
  • Mounting Flange Diameter: 90mm
  • Mounting Hole Diameter: 7mm
  • Mounting Holes Number: 2N
  • Bolt Circle Diameter: 76 mm
  • Dimensions: 3 9/16''H x 9 7/16''W x 6 5/16''D
    MANUALS & DOWNLOADS

    PH2017 - Manuals

    PH2017 - Manuals
